Scilogex Laboratory Refrigerator/Freezer Combination Units | So-Low

Product image 1
Product image 2
Product image 3
Product image 4
Product image 5

Scilogex Laboratory Refrigerator/Freezer Combination Units | So-Low

Scilogex Laboratory Refrigerator/Freezer Combination Units | So-Low

Units come standard with microprocessor digital controller, audible and visual alarms, alarm relay contacts, casters, locking doors and 2 year parts and labor and 5 year compressor warranty.

Product Specifications:

Model DH-10RFC DH-20RFC DH-20RF DH-48RF DH-70RF
Capacity[ Cubic Feet] 10.2 Cu. Ft. 18.33 Cu. Ft. 18 Cu. Ft. 48 Cu. Ft. 70 Cu. Ft.
Capacity[ Liters ] 289 Liters 519 Liters 514 Liters 1358 Liters 1998 Liters
Dimensions [ W x D x H ]
Exterior [ Inches ] 25.5" x 25.75" x 72.75" 36" x 29.25" x 77.75" 27.5" x 34" x 81.5" 52" x 34.75" x 81.5" 78" x 34.75' x 81.5"
Exterior [ Centimeters ] 75 x 65 x 185 91 x 74 x 197 70 x 86 x 207 132 x 88 x 207 198 x 88 x 207
Fridge Interior [ IN ] 23" x 20" x 26" 29.5" x 24" x 29" 28" x 28" x 20" 22" x 28" x 60" 48" x 28" x 60"
Freezer Interior [ IN ] 19" x 18" x 19" 25.5" x 22" x 22.25" 28" x 28" x 20" 22" x 28" x 60" 28" x 28" x 20"
Fridge Interior [ CM ] 60 x 51 x 67 75 x 61 x 74 71 x 71 x 50 55 x 71 x 152 121 x 71 x 152
Freezer Interior [ CM ] 50 x 46 x 51 65 x 56 x 57 71 x 71 x 50 55 x 71 x 152 71 x 71 x 50

Temperature Specifications:

Model DH-10RFC
 DH-20RFC
 DH-20RF
 DH-48RF
 DH-70RF
Refrigerator
 2°C to 8°C 35°F to 46°F
Freezer
 -10°C to -26°C 14°F to -14.8°F
 0°C to -23°C 32°F to -10°F



Electrical Specifications:

  • Voltages Available: 115 Volts 60 Hertz 1 Phase

  • 2 Running Amps: 15 Amp Dedicated Line
                                1.85 Running Amps

  • NEMA Configuration: NEMA 5-15

  • Certification(s): UL Listed

Control Specifications:

Model DH-10RFC DH-20RFC DH-20RF DH-48RF DH-70RF
Temperature Control Two Digital Displays [ Freezer / Refrigerator ]
Min / Max Temperature Display and Reset
Temperature Alarm Audible High / Low Alarm
Alarm Types Door Ajar, Power Failure, Low Battery, Sensor Failure, USB Failure
Data Logging Adjustable Intervals
Data Download Via USB. PDF Format
Backup Battery Only Powers Alarm
Alarm Relay Dry Contacts


General Specifications:

Model
 DH-10RFC
 DH-20RFC
 DH-20RF
 DH-48RF
 DH-70RF
REFRIGERATOR
Defrost
 Automatic
Air Circulation
 Direct Gravity Flow
Compressor(s)
 Hermetic Compressor
Refrigeration
 R600a R290
Insulation
 US EPA Approved SNAP Approved
Opening
 1 Front Door
Opening Type
 Hinged
Door Material
 Insulated Steel Viewing Window Insulated Steel
Lockable Door
 Lockable with Padlock Keyed Lock
Access Porthole
 1" Diameter 1/2" Diameter
Storage
 3 Adjustable Shelves
Exterior
 Painted Steel Stainless Steel
Interior
 Stainless Steel
Casters
 4 4 Locking 6 Locking
Leveling Legs
 4 N/A
Warranty
 2 Years Parts and Labor 3 Years Parts and Labor Additional 4 Years on Compressor Parts
Model DH-10RFC DH-20RFC DH-20RF DH-48RF DH-70RF
FREEZER
Defrost Automatic
Air Circulation Forced Air Gravity Flow
Compressor(s) Hermetic Compressor
Refrigeration R600a R290
Insulation US EPA Approved SNAP Approved Polyurethane
Opening 1 Front Door 1 or 2 Front Door(s)*
Opening Type Hinged
Door Material Insulated Steel
Lockable Door Lockable with Padlock Keyed Lock
Access Porthole 1" Diameter 1/2" Diameter
Storage 3 Fixed Shelves 2 Adjustable Shelves 3 Adjustable Shelves
Exterior Painted Steel Stainless Steel
Interior Painted Steel Stainless Steel
Casters 4 4 Locking 6 Locking
Leveling Legs N/A
Warranty 2 Years Parts and Labor 3 Years Parts and Labor Additional 4 Years on Compressor Parts

This product ships directly from Scilogex, ensuring fast delivery, proper handling, and factory quality. When you purchase Scilogex, you’re backed by a trusted name in laboratory equipment—known for precision, reliability, and dependable support. Shop with confidence knowing your order is fulfilled directly by the manufacturer.
